| Artículo | Diám. mm |
Diám. pulg |
Circ. pulg |
B.L. ton |
Peso kg/220m |
|
| 163005R | 5 | 3/16 | 5/8 | 0.42 | 2.60 | |
| 163006R | 6 | 1/4 | 3/4 | 0.60 | 4.00 | |
| 163008R | 8 | 5/16 | 1 | 0.70 | 6.60 | |
| 163010R | 10 | 3/8 | 1 1/4 | 1.09 | 9.90 | |
| 163012R | 12 | 1/2 | 1 1/2 | 1.54 | 14.30 | |
| 163014R | 14 | 9/16 | 1 3/4 | 2.09 | 19.80 | |
| 163016R | 16 | 5/8 | 2 | 2.80 | 25.30 | |
| 163018R | 18 | 3/4 | 2 1/4 | 3.47 | 32.60 | |
| 163020R | 20 | 13/16 | 2 1/2 | 4.27 | 39.60 | |
| 163024R | 24 | 15/16 | 3 | 6.10 | 57.20 | |
| 163028R | 28 | 1 1/8 | 3 1/2 | 8.20 | 78.10 | |
| 163032R | 32 | 1 1/4 | 4 | 10.70 | 101.20 | |
| 163036R | 36 | 1 7/16 | 4 1/2 | 13.50 | 128.70 |
